H01N2-D Rubber Insulated Welding Cable, plain annealed flexible copper wire conductor, class 5 or class 6 strand, rubber compound insulation, 450/750V, 0.6/1kV, meet to IEC 60245, JB/T 8735, GB/T 5013, BS EN 50525, VDE 0282, BS 638 Part 4.
Brand:
ElectricaltechItem NO.:
XTD-Special-06Order(MOQ):
1000 metersPayment:
T/T 30% the deposit, the balance will be paidMarket Price:
$/M 8.88Price:
$6.88/8.66 per meterProduct Origin:
Hubei Province, China.Color:
Black red or orange.Shipping Port:
Wuhan, Shanghai, Guangzhou, Shenzhen, or other Chinese port.Lead Time：
Within 7-10 working days as soon as weWeight：
780 KG/KM
H01N2-D Rubber Insulated Welding Cable
MAIN KEYWORDS
H01N2-D welding cable, rubber insulated welding cable, heavy duty welding cable, flexible rubber welding cable.
PRODUCTS APPLICATION
Electricaltech@ brand H01N2-D Rubber Insulated Welding Cable, is used as a connection to welding robots in the automotive industry, shipyards and for manually/automatically operated lines and spot welding. These cables are ideal for use as an interconnecting battery cable or in battery storage systems. The robust cable structure makes them resistant to low and high temperatures, ozone and radiation, oils, acids, fats and petrol.
PRODUCTS STRUCTURE
---Conductor Material
Plain annealed copper wire, strand, class 5 or class 6.
---Separator Material
PET (Polyester Tape)
---Insulated Material
Rubber compound
---Insulated Color
Black, red, orange, or others.
---Core Quantity
Single Core, 1C.
---Conductor Cross-section
16～150 mm2
---Voltage Rate
450/750V, 0.6/1kV
---Temperature Rating
-15～+90 °C
---Minimum Bending Radius
Fixed: -40°C to +85°C
Flexed: -20°C to +85°C
---Production Standard
JB/T 8735-2016, GB/T 5013-2008, GB/T 19666, IEC 60245, BS EN 50525.
---Production Delivery
Within 7-10 working days as soon as we received the 30% deposit before the shipment.
---Packing Type
100 meters per roll, plastic reel, plywood drum, wooden pallet, wooden drum or others.
REMARK
---The information contained within this datasheet is for guidance only and is subject to change without notice or liability.
---All the information is provided in good faith and is believed to be correct at the time of publication; when selecting cable accessories, please note that actual cable dimensions may vary due to manufacturing tolerances.
---The OEM or OBM service will be accepted, but the customer should be provided the authorization letter to us in advance, and the authorization letter must be true and valid.
---Electricaltech Cable: Embrace New Times, Co-create Xintiandi; Focus on Quality, Foremost Service.
---Electricaltech Cable: Good Material, Reasonable Weight, Enough Length, well-known brand wins your trust.
---Electricaltech Cable: it is your Production Base, Overseas Warehouse, Purchase Consultant in wire and cable industry.
